Universal Rapid Clamp

Composition and Material:

This clamping block consists of three main parts: a pressure block, bolts, and a nut. The pressure block is made of AL6005-T5, the bolts are made of SUS304, and the nut is made of S350. These materials all possess excellent corrosion resistance and self-healing capabilities, allowing the universal rapid clamp to be used in C3 environments.

Installation and Operation:

During installation, simply place the clamping block in the designated position on the rail and press it in firmly to complete the installation. When used as a side clamp for solar PV modules, the cutout direction of the clamping block should be parallel to the side of the nut; when used as a mid clamp for solar PV modules, the cutout direction of the clamping block should be perpendicular to the side of the nut.

Functional Advantages:

The clamp always floats above the track during adjustment, a design that allows it to accommodate modules of varying thicknesses. Installation is easily completed simply by adjusting the depth of the bolt screwed into the nut. The Adjustable solar panel clamp 30-45mm can withstand a pull-out force test of 15KN. The upper surface of the clamp is flat, forming surface contact with the solar module surface, enhancing pressure on the module and reducing damage caused by point contact. The clamp surface undergoes an AA10~15 anodizing treatment, making it resistant to corrosion, increasing the lifespan of the solar panel, and improving the power plant's power generation efficiency.

Information Sheet

Material: AL6005-T5.

Specification: 35-50mm length, customized.

Color: Natural or black anodized.

Installation site: Solar mounting rails.

Wind Speed : 60m/s.

Warranty:12 years warranty, 25 years life time.

Packing:140-160 pcs for one carton.

Conclusion

Structurally: Surface contact installation, safer than point contact installation.

In terms of usability: Compatible with most components on the market.

In terms of installation: Quick installation, reducing installation time by 30% compared to ordinary clips.

In terms of transportation: Packed in boxes and pallets, lightweight.

Q&A

Q:How long is the production cycle for this clamp?

A:Production will be completed within 2 weeks after the prepayment is received, and delivery will be made according to the nearest shipping schedule.

Q:Are there compatible tracks for the clamp sold?

A:Yes, we can sell the entire set, including hooks, tracks, and clamps.

Q:Can the clamp withstand a C4 salt-prone environment?

A:Yes, the surface can be anodized with AA15, and the bolts are made of SUS316 stainless steel.
